Diphenyl Ether

Diphenyl ether
Names
	Preferred IUPAC name 1,1′-Oxydibenzene
	Other names Oxydibenzene; Diphenyl ether; Diphenyl oxide; 1,1′-Oxybisbenzene; Phenoxybenzene
Identifiers
CAS Number	101-84-8 ;
3D model (JSmol)	Interactive image;
Beilstein Reference	1364620
ChEBI	CHEBI:39258 ;
ChEMBL	ChEMBL38934 ;
ChemSpider	7302 ;
EC Number	202-981-2;
Gmelin Reference	165477
PubChem CID	7583;
RTECS number	KN8970000;
UNII	3O695R5M1U ;
UN number	3077
	InChI InChI=1S/C12H10O/c1-3-7-11(8-4-1)13-12-9-5-2-6-10-12/h1-10H Key: USIUVYZYUHIAEV-UHFFFAOYSA-N ; InChI=1/C12H10O/c1-3-7-11(8-4-1)13-12-9-5-2-6-10-12/h1-10H Key: USIUVYZYUHIAEV-UHFFFAOYAV;
	SMILES O(c1ccccc1)c2ccccc2;
Properties
Chemical formula	C12H10O
Molar mass	170.211 g·mol−1
Appearance	Colorless solid or liquid
Odor	geranium-like
Density	1.08 g/cm3 (20 °C)
Melting point	25 to 26 °C (77 to 79 °F; 298 to 299 K)
Boiling point	258.55 °C (497.39 °F; 531.70 K) at 100 kPa (1 bar),; 121 °C at 1.34 kPa (10.05 mm Hg)
Solubility in water	Insoluble
Vapor pressure	0.02 mmHg (25 °C)
Magnetic susceptibility (χ)	-108.1·10−6 cm3/mol
Hazards
Safety data sheet	Aldrich MSDS
GHS pictograms
GHS Signal word	Warning
GHS hazard statements	H319, H400, H411
GHS precautionary statements	P264, P273, P280, P305+351+338, P337+313, P391, P501
NFPA 704 (fire diamond)	1 2
Flash point	115 °C (239 °F; 388 K)
Explosive limits	0.7%–6.0%
	Lethal dose or concentration (LD, LC):
LD50 (median dose)	3370 mg/kg (rat, oral); 4000 mg/kg (rat, oral); 4000 mg/kg (guinea pig, oral)
	NIOSH (US health exposure limits):
PEL (Permissible)	TWA 1 ppm (7 mg/m3)
REL (Recommended)	TWA 1 ppm (7 mg/m3)
IDLH (Immediate danger)	100 ppm
	Except where otherwise noted, data are given for materials in their standard state (at 25 °C [77 °F], 100 kPa).
	verify (what is ?)
	Infobox references

Diphenyl ether is the organic compound with the formula (C₆H₅)₂O. It is a colorless, low-melting solid. This, the simplest diaryl ether, has a variety of niche applications.^[5]

Synthesis and reactions

Diphenyl ether and many of its properties were first reported as early as 1901.^[6] It is synthesized by a modification of the Williamson ether synthesis, here the reaction of phenol and bromobenzene in the presence of base and a catalytic amount of copper:

PhOH + PhBr → PhOPh + HBr

Involving similar reactions, diphenyl ether is a significant side product in the high-pressure hydrolysis of chlorobenzene in the production of phenol.^[7]

Related compounds are prepared by Ullmann reactions.^[8]

The compound undergoes reactions typical of other phenyl rings, including hydroxylation, nitration, halogenation, sulfonation, and Friedel–Crafts alkylation or acylation.^[5]

Uses

The main application of diphenyl ether is as a eutectic mixture with biphenyl, used as a heat transfer fluid. Such a mixture is well-suited for heat transfer applications because of the relatively large temperature range of its liquid state. A eutectic mixture (commercially, Dowtherm A) is 73.5% diphenyl ether and 26.5% biphenyl.^[9]^[10]

Diphenyl ether is a starting material in the production of phenoxathiin via the Ferrario reaction.^[11] Phenoxathiin is used in polyamide and polyimide production.^[12]

Because of its odor reminiscent of scented geranium, as well as its stability and low price, diphenyl ether is used widely in soap perfumes. Diphenyl ether is also used as a processing aid in the production of polyesters.^[5]

Related compounds

It is a component of important hormone T3 or triiodothyronine.

Several polybrominated diphenyl ethers (PBDEs) are useful flame retardants. Of penta-, octa-, and decaBDE, the three most common PBDEs, only decaBDE is still in widespread use since its ban in the European Union in 2003.^[13] DecaBDE, also known as decabromodiphenyl oxide,^[14] is a high-volume industrial chemical with over 450,000 kilograms produced annually in the United States. Decabromodiphenyl oxide is sold under the trade name Saytex 102 as a flame retardant in the manufacture of paints and reinforced plastics.
